Genau Gantry milling machines 3-Axis Milling Onsite Precision.

The 3-Axis Gantry Milling Machine is a portable powerhouse designed for onsite machining of surfaces demanding high accuracy and excellent surface finishes. This versatile machine is engineered to handle a wide array of applications, offering a substantial machining capability of up to 4000 mm x 35000 mm x 200 mm. Bring the capabilities of a stationary milling centre directly to your worksite, eliminating the complexities and costs associated with transporting large components.

Built for demanding heavy-duty tasks, the 3-Axis Gantry Milling Machine maintains ease of handling for operators. It is driven by a robust hydraulic or pneumatic motor, featuring an ISO40 spindle for efficient material removal. Its adaptable design allows for mounting in horizontal, vertical, inclined, and even overhead positions, catering to diverse surface milling requirements. Furthermore, the milling cutter's ability to tilt up to 45° on both sides significantly enhances its versatility for machining engine mounting pads, GT mounting pads, gearbox mounting pads, motor foundations, square and rectangular flanges, slots, grooves, gasket areas, girders, and heavy construction girders.
